Automatic Fluid Drying Machine

Automatic Fluid Drying Machine

Working Principle: The powder granule in fluid bed appears in the state of fluidization. It is preheated and mixed with ;
Basic Info
Model NO. FL-200
Customized Customized
Condition New
Warranty 5 Year
Item Name Automatic Fluid Drying Machine
Model Fl-200
Batch Time 10-30minute/Bacth
Capacity 300kg
Material Consist Ss304(Ss316 Is Available)
Working Principle Powder Mixed with Spay Granulate and Dry Through H
Application Powder
Control System PLC Control or Micro Computer
Operation System Touch Screen or Button Operation
Safety Protector Available
Transport Package Wooden Case
Specification CE, GMP
Trademark LTPM China
Origin China
HS Code 8479899990
Production Capacity 25 Sets/Month
Product Description

Automatic Fluid Drying Machine



Working Principle:
The powder granule in fluid bed appears in the state of fluidization. It is preheated and mixed with clean and heated air. At the same time the solution of adhesive is sprayed into the container. It makes the particles become granulating that contains adhesive. Being of unceasing dry through hot air, the moisture in the granulating is evaporated. The process is carried out continuously. Finally it forms ideal, uniform and porous granules.


Features

1. Through powder granulating, the flow property is improved and the dust is reduced.
2. Through powder granulating, its solving property is improved.
3. The mixing, granulating and drying can be completed in one step inside the machine.
4. The operation of equipment is safe because the anti static filtering cloth is adopted.
5. The operation personnel can not be damaged of explosion take place because of the releasing hole.
6. The equipment has no dead corner. Therefore the loading and unloading, quick and light and clean. It can
meet the requirements of GMP.



Related Products


Item

Unit

Specific

3

5

15

30

60

120

200

300

500

1000

vessel

volume

L

12

22

45

100

220

420

670

1000

1500

3000

diameter

mm

300

400

550

700

1000

1200

1400

1600

1800

2200

capability

min

kg

1.5

4

10

15

30

80

100

150

250

800

max

4.5

6

20

45

90

160

300

450

750

1200

fan

velocity

m3/h

1000

1200

1400

1800

3000

4500

6000

7000

8000

13670

pressure

mmH2O

375

480

950

1400

power

kw

3

4

5.5

7.5

11

18.5

30

37

45

90

steam consumption

kg/h

15

23

42

70

141

211

282

366

451

750

compressed air expenditure

m3/min

0.9

1.0

1.1

1.5

3.0

4.0

weight of the main body

kg

500

700

900

1000

1100

1300

1500

1800

2500

3500

steam pressure

MPA

0.1-0.4

temperature


Adjustable at the range from room temperature to 120

working time

min

45-90 decided in accordance with the properties of raw materials

collect rate

%

≥99

noise

dB(A)

≤75dB (A) during installation, main machine is separated from fan.

size (L×W×H)

m

1.0×0.6 ×2.1

1.2×0.7×2.3

1.25×0.9 ×2.5

1.6×1.1×2.5

1.85 ×1.4×3

2.2×1.65×3.3

2.34×1.7 ×3.8

2.8×2.0×4.5

3×2.25×5.0

4×2.8×7.2

Automatic Fluid Drying Machine

Automatic Fluid Drying Machine

Automatic Fluid Drying Machine

Automatic Fluid Drying Machine



Q: What price terms you offer?
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.

Q: What payment terms you take?
A: TT, LC, other terms are also workable.

Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should
bear our technician's round tickets, accomodation, food and subsidiary USD100/day.

Q: How can I visit your factory?
A: Our factory is located in Ruian city Zhejiang Province. Just let us know your scheduel in advance and we will arrange
everything for you!
Any other doubts about our machine, please feel easy to contact with us.
